The hydraulic V-Top surgery table offers hands-free height adjustment. Pump foot pedal to raise, depress pedal to lower. The full 6" range is 32 1/2" to 39 1/2". The table top tilts from level to 37° via single finger-tip control, no knobs to loosen or tighten are needed. A one-hand, finger-tip control adjusts side panels from flat to 95° “V” via smooth operating pneumatic cylinders. The table top and V-panels are counterbalanced for easier positioning of the patient. The table comes with a reservoir drainage system and the center drain trough slides out for easy cleaning. Optional heated top available.
Table measurements
50" or 60" L x 20" W with adjustable height
Base measurements
24" L x 18" W
Height adjustment
33 ½” - 39 ½” - quietly and smoothly raises and lowers
Stainless steel top
18 gauge stainless steel top panels measure 50" or 60" L x 9 7/8" W - have 1 1/8" thick inner board for a solid, quiet working surface
100-4041-00 50" V-Top Surgery Table - Hydraulic Column - Without Heated Top
100-4041-21 50" V-Top Surgery Table - Hydraulic Column - With Heated Top
100-4071-00 60" V-Top Surgery Table - Hydraulic Column - Without Heated Top
100-4071-21 60" V-Top Surgery Table - Hydraulic Column - With Heated Top
