PowerVac® Dry Vacuums
The first dry vacuum to combine the advanced features your dental practice demands into one flexible, performance-driven system. The PowerVac creates a new standard for dental dry vacuums with exceptional power and performance.
Features:
- Oil-less and waterless design
- Quiet operation
- Consistent high performance – up to 18” Hg
- Compact design, with floor space requirements comparable to conventional wet-ring vacuums
- Upgradeable to accommodate 1-20 users
- Can replace many types of existing vacuum technologies, regardless of plumbing configuration
- Unmatched product warranty ‐ 5-yr/10,000-hr full-product; 10-yr/20,000-hr pump
- Complies with NFPA 99C Level 3
-
Technical Specifications
Model: P3 (Single)
No. users: 3 – 5
No. vacuums: 1
Total HP: 2
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4
Overall dimensions H x W x D: 58" x 22" x 22"
Base dimensions H x W x D: 26" x 19.5" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb
Tank – 90 lbModel: P5 (Single)
No. users: 5 – 7
No. vacuums: 1
Total HP: 2
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4
Overall dimensions H x W x D: 58" x 22" x 22"
Base dimensions H x W x D: 26" x 19.5" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb
Tank – 90 lbModel: P6 (Twin)
No. users: 6 – 10
No. vacuums: 2
Total HP: 4
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4 x 2
Overall dimensions H x W x D: 58" x 56" x 22"
Base dimensions H x W x D: 26" x 39" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb x 2
Tank – 90 lb x 2Model: P7 (Single)
No. users: 7 – 10
No. vacuums: 1
Total HP: 2
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4
Overall dimensions H x W x D: 58" x 22" x 22"
Base dimensions H x W x D: 26" x 19.5" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb
Tank – 90 lbModel: P10 (Twin)
No users: 10 – 14 No.
No vacuums: 2
Total HP: 4
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4 x 2
Overall dimensions H x W x D: 58" x 56" x 22"
Base dimensions H x W x D: 26" x 39" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb x 2
Tank – 90 lb x 2Model: P14 (Twin)
Users: 14 – 20
No. vacuums: 2
Total HP: 4
Vacuum ("Hg): up to 18
Voltage: 208-230/60 Hz
Total amps: 11.4 x 2
Overall dimensions H x W x D: 58" x 56" x 22"
Base dimensions H x W x D: 26" x 39" x 18.5"
Tank dimensions H x W x D: 32" x 22" x 22"
Shipping weight:
Base – 402 lb x 2
Tank – 90 lb x 2 -
