Artizan® Expressions Treatment Stations

80 Series

TS3680 Treatment Station
Total height 72", width 36"
Base depth 22.25" (countertop), 36" (with worksurface)
Two-compartment upper module (TS-100 with lift system)
Midsection (TS-700)
Base module (TS-300 or TS-405)
Center module (TS-500)
Pivoting left/right worksurface
Finished back with lower rear-access service doors

TS4380 Treatment Station
Total height 72", width 43.5"
Base depth 22.25" (countertop), 36" (with worksurface)
Three-compartment upper module (TS-100 with lift system)
Midsection (TS-700)
Base module (TS-300 or TS-405)
Center module (TS-500)
Pivoting left/right worksurface
Finished back with lower rear-access service doors

TS4385 Treatment Station
Total height: 72", width: 43.5"
Base depth: 26.125" (countertop), 39" (with worksurface)
Three compartment upper module (TS-100 with lift system)
Midsection (TS-700)
Base module (TS-300 or TS-405)
Center module (TS-500)
Pivoting left/right worksurface
Dedicated CPU side-storage module
Finished back with lower rear-access service doors

90 Series

TS3690 Treatment Station
Total height 72", width 36"
Base depth 17.625" (countertop), 29.625" (with worksurface)
Two compartment upper module (TS-100 with lift system)
Midsection (TS-700)
Base module (TS-300 or TS-405)
Center module (TS-500)
Pivoting left/right worksurface
Finished back (freestanding)

TS4390 Treatment Station
Total height: 72", width: 43.5"
Base depth: 17.625" (countertop), 29.625" (with worksurface)
Three compartment upper module (TS-100 with lift system)
Midsection (TS-700)
Base module (TS-300 or TS-405)
Center module (TS-500)
Pivoting left/right worksurface
Finished back (freestanding)

Standard panel color options
20 cabinet color selections
1-color or 2-color tone options
Non-standard panel colors available at additional cost

Standard countertop options
11 Wilsonart^® and Formica^® laminate colors
16 Corian^® solid-surface colors
13 Zodiaq^® and Viatera^® quartz colors
Non-standard laminates, Corian solid-surface and Zodiaq Quartz colors available at additional cost

Midmark instrument delivery options

Available on TS3680, TS4380, TS4385, TS3690, TS4390
153659-003 Pivoting worksurface only
153659-004 Pivoting worksurface and assistant's instruments
153659-002 Pivoting worksurface, assistant's instruments and procenter delivery system

Available on TS3670, TS4370, TS4375 153659-008: Assistant's instruments and procenter delivery system (sliding worksurface included on cabinet)
153659-009 Assistant's instruments (sliding worksurface included on cabinet)
